Tractor · 1981Unverified
International Harvester 1486B
International Harvester 1486B — 86B Series · 125 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
125 hp
Weight
6065 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Row-Crop tractorReference
Built in Geelong, AustraliaReference
Total built64Reference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard.Reference
Engine
International Harvester 7.1L 6-cyl dieselReference
Engine124.5 kWReference
International Harvester DT-436Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement7.1 LReference
Bore/Stroke109 x 127 mmReference
Power124.5 kWReference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
16-speed Torque AmplifierReference
Transmissiontwo-speed power shiftReference
TypeTorque AmplifierReference
Gears16 forward and 4 reverseReference
Clutchhydraulic cerametallic discReference
PTO & Hydraulics
PTO (claimed)93.2 kWReference
Typeopen centerReference
Rear TypeIII/IIReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM1000@2300Reference
Dimensions
Weight6065 kgReference
Front tire11.00-16Reference
Rear tire24.5-32Reference
Ag front11.00-16Reference
Ag rear24.5-32Reference
Length426 cmReference
Width259 cmReference
Height (cab)290 cmReference
Ground clearance39 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
