Industrial Tractor · 1978Unverified

International Harvester 165

Name: International Harvester 165
Brand: International Harvester

International Harvester 165 — Crawler Loader · 80 hp. Reference specifications; pending source verification.

The International Harvester 165 is an industrial tractor with an engine rating of approximately 80 hp, which falls within the mid-range for its class. Produced from 1978 to 1982, this model features a 6-cylinder diesel liquid-cooled engine paired with a tracked undercarriage and a powershift transmission. It has an operating weight of 11517 kg and is suited to operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

80 hp

Weight

11517 kg

Catalogue coverage

Variants represented

Richest spec table

40 rows

Recorded power

80 hp

Recorded weight

11517 kg

Transmissions

2-speed power shift

Production years

1978-1982

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerInternational HarvesterReference

Crawler LoaderReference

DrivecrawlerReference

Final drivesplanetaryReference

Four-post ROPS. Cab optional with heater.Reference

Engine

International Harvester 5.1L 6-cyl dieselReference

Engine (net)59.7 kWReference

International Harvester D-310Reference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement5.1 LReference

Bore/Stroke98 x 111 mmReference

Power (net)59.7 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Oil capacity17.4 LReference

Coolant capacity19.3 LReference

Transmission

2-speed power shiftReference

Typepower shiftReference

Gears2 forward and reverseReference

Oil capacity40.7 LReference

Capacities

Fuel149.9 LReference

PTO & Hydraulics

Hydraulic system104.1 LReference

Typeclosed centerReference

Capacity104.1 LReference

Pressure155.1 barReference

Pump flow136.3 lpmReference

Dimensions

Weight11517 kgReference

14-inch tracksReference

Length473 cmReference

Height (ROPS)290 cmReference

Operating weight11517 kgReference

International Harvester 165 attachments

front-end loaderReference

International Harvester 165 Tracks

Width35 cmReference

Length on ground216 cmReference

Area on ground1.5 m²Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
