Industrial Tractor · 1978Unverified
International Harvester 165
International Harvester 165 — Crawler Loader · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
11517 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Crawler LoaderReference
DrivecrawlerReference
Final drivesplanetaryReference
Four-post ROPS. Cab optional with heater.Reference
Engine
International Harvester 5.1L 6-cyl dieselReference
Engine (net)59.7 kWReference
International Harvester D-310Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.1 LReference
Bore/Stroke98 x 111 mmReference
Power (net)59.7 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity17.4 LReference
Coolant capacity19.3 LReference
Transmission
2-speed power shiftReference
Typepower shiftReference
Gears2 forward and reverseReference
Oil capacity40.7 LReference
Capacities
Fuel149.9 LReference
PTO & Hydraulics
Hydraulic system104.1 LReference
Typeclosed centerReference
Capacity104.1 LReference
Pressure155.1 barReference
Pump flow136.3 lpmReference
Dimensions
Weight11517 kgReference
14-inch tracksReference
Length473 cmReference
Height (ROPS)290 cmReference
Operating weight11517 kgReference
International Harvester 165 attachments
front-end loaderReference
International Harvester 165 Tracks
Width35 cmReference
Length on ground216 cmReference
Area on ground1.5 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
