Industrial Tractor · 1972Unverified
International Harvester 175C
International Harvester 175C — Crawler Loader · 130 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
130 hp
Weight
13905 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Crawler LoaderReference
DrivecrawlerReference
Final drivesplanetaryReference
Four-post ROPS.Reference
Variants
TD-15CbulldozerReference
175Ccrawler-loaderReference
Engine
International Harvester 7.6L 6-cyl dieselReference
Engine (net)96.9 kWReference
International Harvester DT-466Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.6 LReference
Bore/Stroke109 x 136 mmReference
Power (net)96.9 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM2400Reference
StarterelectricReference
Starter volts24Reference
Oil capacity21.8 LReference
Coolant capacity41.6 LReference
Transmission
4-speed power shiftReference
Typepower shiftReference
Gears4 forward and reverseReference
Oil capacity132.5 LReference
Capacities
Fuel227.1 LReference
PTO & Hydraulics
Hydraulic system90.8 LReference
Typeopen centerReference
Capacity90.8 LReference
Pressure69.0 barReference
Pump flow196.8 lpmReference
Dimensions
Weight13905 kgReference
15-inch tracksReference
Length500 cmReference
Operating weight13905 kgReference
Gauge167 cmReference
International Harvester 175C attachments
front-end loaderReference
175C Serial Numbers
1972501Reference
19731204Reference
19741888Reference
19752489Reference
19762791Reference
19772843Reference
19783171Reference
19793591Reference
19803726Reference
19813756Reference
19823849Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemalternatorReference
Charging amps35Reference
Batteries4Reference
Battery volts6Reference
International Harvester 175C Tracks
Width38 cmReference
Length on ground220 cmReference
Area on ground1.7 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
