Industrial Tractor · 1977Unverified
International Harvester 238
International Harvester 238 — Industrial tractor · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
2222 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Industrial tractorReference
Two-wheel driveReference
Final drivesspiral bevel gearReference
Differential lockmechanical rearReference
Steeringpower assistReference
Disc brakesReference
Two-post ROPS. Canopy optional.Reference
Variants
384ag utility tractorReference
Engine
International 2.5L 4-cyl dieselReference
Engine (gross)22.4 kWReference
Engine (net)21.1 kWReference
International BD-154Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke89 x 102 mmReference
Power (net)21.1 kWReference
Power (gross)22.4 kWReference
Air cleanerdryReference
Rated RPM2100Reference
Starter volts12Reference
Oil capacity7.6 LReference
Coolant capacity10.2 LReference
Transmission
8-speed sliding spur gear with mechanical reverserReference
8-speedReference
Typesliding spur gear with mechanical reverserReference
Gears8 forward and reverseReference
Clutch279mm dry discReference
Oil capacity35.2 LReference
Four gears (1-4) in two ranges (low/high) with mechanical reverser.Reference
Gears8 forward and 2 reverseReference
Optional 8-2 transmission.Reference
Capacities
Fuel45.4 LReference
PTO & Hydraulics
Hydraulic system35.2 LReference
Typeopen centerReference
Capacity35.2 LReference
Pressure158.6 barReference
Pump flow29.5 lpmReference
Rear TypeIReference
Controlhydraulic draft controlReference
Rear PTOliveReference
Clutchdual-stage 229mm dry discReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase194 cmReference
Weight2222 kgReference
Front tire7.5-16Reference
Rear tire14.9-24Reference
Industrial front7.5-16Reference
Industrial rear14.9-24Reference
Industrial front6.0-16Reference
Industrial rear13.6-28Reference
Length431 cmReference
Width169 cmReference
Height (ROPS)223 cmReference
Shipping weight2222 kgReference
Max front axle2721 kgReference
Front tread121 cmReference
Rear tread132 cmReference
International Harvester 238 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps28Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
