Backhoe Loader · 1974Unverified
International Harvester 2412B
International Harvester 2412B — Backhoe loader tractor · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
10210 to 10490 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Backhoe loader tractorReference
Built in Louisville, Kentucky, USAReference
The Interntional 2412B was a variant of the 2400B equipped with the heavy-duty Pay Loader and backhoe.Reference
Two-wheel driveReference
Power steeringReference
Hydraulic disc brakesReference
Four-post ROPS.Reference
Variants
2400Butility tractorReference
2405Butility loaderReference
2410BPay LoaderReference
2412Bloader-backhoeReference
Engine
International Harvester 2.9L 3-cyl dieselReference
International Harvester 2.6L 4-cyl gasolineReference
International Havester 2.9L 4-cyl gasolineReference
Engine (gross)40.3 kWReference
Engine (net)34.3 kWReference
International Harvester D-179Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke98 x 129 mmReference
Power (net)34.3 kWReference
Power (net)37.3 kWReference
Power (gross)40.3 kWReference
Power (gross)43.3 kWReference
Rated RPM2200 (gear)Reference
Rated RPM2400 (hydro)Reference
Coolant capacity11.8 LReference
International Harvester C-157Reference
gasolineReference
4-cylinderReference
The C-157 engine was the gasoline engine used on the 2410B when equipped with the 8-speed transmissions.Reference
Displacement2.6 LReference
Bore/Stroke86 x 112 mmReference
Power (net)34.3 kWReference
Power (gross)38.8 kWReference
Rated RPM2200Reference
Coolant capacity10.9 LReference
International Havester C-175Reference
The C-175 was the gasoline engine for the International 2410B with the hydrostatic transmission.Reference
Displacement2.9 LReference
Bore/Stroke90 x 112 mmReference
Power (net)39.5 kWReference
Power (gross)44.7 kWReference
Rated RPM2400Reference
Transmission
8-speed synchromeshReference
8-speed hydraulic reverserReference
hydrostaticReference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
Typehydraulic reverserReference
Gears8 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Total flow96.5 lpmReference
Total flow45.4 lpmReference
Total flow51.1 lpmReference
Steering flow9.5 lpmReference
Steering press.165.5 barReference
Dimensions
Wheelbase203 cmReference
Weight10210 to 10490 poundsReference
Front tire7.50-16Reference
Rear tire14.9-24Reference
Industrial front7.50-16Reference
Industrial rear14.9-24Reference
Length664 cmReference
Width201 cmReference
Height (steering wheel)137 cmReference
Height (ROPS)259 cmReference
Ground clearance22 cmReference
Front tread137 to 187 cmReference
Rear tread162 cmReference
Shipping4631 kgReference
Shipping4667 kgReference
Shipping4721 kgReference
Shipping4758 kgReference
Max front axle4536 kgReference
Backhoe & Loader
Dig depth373 cmReference
Dump angle114 cmReference
Attachment overview
Front-end loaderReference
BackhoeReference
International Pay Hoe Backhoe
Backhoe typeInternational Pay Hoe BackhoeReference
Bucket width60 cmReference
Digging depth373 cmReference
Reach from pivot500 cmReference
Loading height327 cmReference
Bucket force3504 kgReference
Dipperstick force2191 kgReference
Speeds
With 14.9-24 rear tires.Reference
With 14.9-24 rear tires. Reverse speeds about 25% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
