Industrial Tractor · Unverified
International Harvester 2504
International Harvester 2504 — Industrial tractor · 58 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
58 hp
Weight
4550 to 4740 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Industrial tractorReference
Two-wheel driveReference
Open operator station.Reference
Variants
504farm tractorReference
Engine
International Harvester 2.5L 4-cyl gasolineReference
International Harvester 3.1L 4-cyl dieselReference
Fuel tank57.9 LReference
Engine43.3 kWReference
International Harvester C153Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke86 x 108 mmReference
Power43.3 kWReference
Rated RPM2200Reference
Torque196.6 NmReference
Torque RPM1400Reference
Oil capacity4.7 LReference
Coolant capacity14.2 LReference
International Harvester D188Reference
dieselReference
Displacement3.1 LReference
Bore/Stroke94 x 112 mmReference
Torque191.2 NmReference
Oil capacity6.6 LReference
Coolant capacity17.6 LReference
Transmission
5-speed gearReference
10-speed two-speed power shiftReference
5-speed shuttleReference
TypegearReference
Gears5 forward and 1 reverseReference
TransmissionTorque AmplifierReference
Typetwo-speed power shiftReference
Gears10 forward and 2 reverseReference
TypeshuttleReference
Gears5 forward and reverseReference
Dimensions
Wheelbase186 cmReference
Weight4550 to 4740 poundsReference
Length299 cmReference
Width162 cmReference
Height (steering wheel)152 cmReference
Geas Weight2063 kgReference
Diesel Weight2150 kgReference
Clearance (front axle)48 cmReference
Clearance (rear axle)33 cmReference
Front tread132 cmReference
Rear tread132 to 193 cmReference
Rear tread152/162 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
