Industrial Tractor · 1978Unverified
International Harvester 250A
International Harvester 250A — Industrial tractor · 67 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
67 hp
Weight
5050 to 5250 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Industrial tractorReference
Two-wheel driveReference
Power steeringReference
Independent hydraulic wet disc brakesReference
Two-post fixed ROPS.Reference
Variants
250Aindustrial tractorReference
250A TLBbackhoeReference
Engine
International Harvester 3.9L 4-cyl dieselReference
Engine (gross)50.0 kWReference
Engine (net)44.7 kWReference
International Harvester D-239Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 129 mmReference
Hydro Power (net)52.2 kWReference
Hydro Power (gross)59.7 kWReference
Air cleanerdryReference
Hydro Rated RPM2400Reference
Oil capacity9.5 LReference
Coolant capacity13.2 LReference
Transmission
8-speedReference
Gear Shipping weight2290 kgReference
Gear Power (net)44.7 kWReference
Gear Power (gross)50.0 kWReference
Gear Rated RPM2200Reference
TransmissiongearReference
Gears8 forward and 4 reverseReference
Clutch279mm dry discReference
TransmissionhydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Capacities
Fuel75.7 LReference
PTO & Hydraulics
Hydraulic system53.0 LReference
Typeopen centerReference
Capacity53.0 LReference
Pressure172.4 barReference
Pump flow50.3 lpmReference
Total flow59.8 lpmReference
Steering flow9.5 lpmReference
Rear TypeII/IReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase213 cmReference
Weight5050 to 5250 poundsReference
Front tire7.50x16Reference
Rear tire14.9x24Reference
Industrial front7.50x16Reference
Industrial rear14.9x24Reference
Length350 cmReference
Width200 cmReference
Width210 cmReference
Height (ROPS)227 cmReference
Height (ROPS)219 cmReference
Hydro Shipping weight2381 kgReference
Ground clearance22 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
