Industrial Tractor · 1966Unverified
International Harvester 250B
International Harvester 250B — Crawler Loader · 160 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
160 hp
Weight
39400 to 42250 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Crawler LoaderReference
DrivecrawlerReference
Final drivesplanetaryReference
Open operator station.Reference
Variants
TD-20BbulldozerReference
250Btrack-loaderReference
Engine
International Harvester 7.0L 6-cyl dieselReference
Engine (net)119.3 kWReference
International Harvester DT-429Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.0 LReference
Bore/Stroke114 x 114 mmReference
Power (net)119.3 kWReference
Fuel systemdirect injectionReference
Rated RPM2300Reference
StarterelectricReference
Starter volts24Reference
Oil capacity25.6 LReference
Coolant capacity47.3 LReference
Transmission
4-speed two-speed power shiftReference
Typetwo-speed power shiftReference
Gears4 forward and reverseReference
Capacities
Fuel325.5 LReference
PTO & Hydraulics
Hydraulic system106.0 LReference
Hydraulic system121.1 LReference
Capacity106.0 LReference
Capacity121.1 LReference
Pressure69.0 barReference
Pump flow259.3 lpmReference
Dimensions
Weight39400 to 42250 poundsReference
18-inch tracksReference
Length551 cmReference
Height234 cmReference
Operating weight17871 kgReference
Operating weight19164 kgReference
Ground clearance46 cmReference
Gauge193 cmReference
International Harvester 250B attachments
front-end loaderReference
International Harvester 250B Tracks
Width45 cmReference
Length on ground271 cmReference
Area on ground2.5 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
