Industrial Tractor · 1958Unverified
International Harvester 340
International Harvester 340 — Industrial tractor · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
3900 to 4470 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Industrial tractorReference
Two-wheel driveReference
Final drivesbull gearReference
SteeringmanualReference
SteeringpowerReference
Open operator station.Reference
Variants
IH 340utilityReference
Farmall 340row-cropReference
T-340crawlerReference
International 340industrialReference
Engine
International Harvester 2.7L 4-cyl dieselReference
International Harvester 2.2L 4-cyl dieselReference
Fuel tank56.8 LReference
Engine (gross)35.0 kWReference
Gas Drawbar (claimed)24.2 kWReference
Diesel Drawbar (claimed)26.8 kWReference
International Harvester D-166Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke94 x 98 mmReference
Power (gross)35.0 kWReference
Compression19.2:1Reference
Rated RPM2000Reference
Idle RPM650-2000Reference
Torque174.9 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity17.6 LReference
International Harvester C-135Reference
Displacement2.2 LReference
Bore/Stroke83 x 103 mmReference
Compression7.6:1Reference
Idle RPM900-2000Reference
Torque173.6 NmReference
Torque RPM1200Reference
Starter volts6Reference
Oil capacity4.7 LReference
Coolant capacity14.2 LReference
Transmission
5-speed gearReference
10-speed two-speed power shiftReference
5-speed mechanical shuttleReference
TypegearReference
Gears5 forward and 1 reverseReference
Clutchdry discReference
TransmissionTorque AmplifierReference
Typetwo-speed power shiftReference
Gears10 forward and 2 reverseReference
TransmissionFast ReverseReference
Typemechanical shuttleReference
Gears5 forward and reverseReference
PTO & Hydraulics
Gas PTO (claimed)26.2 kWReference
Diesel PTO (claimed)29.8 kWReference
Pump flow35.2 lpmReference
Pump flow45.4 lpmReference
Pump flow64.3 lpmReference
Steering flow9.5 lpmReference
Rear TypeIReference
TypeIH Fast HitchReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@1747Reference
Dimensions
Wheelbase186 cmReference
Weight3900 to 4470 poundsReference
Front tire5.50-16Reference
Rear tire12.4/11-28Reference
Weight782 kgReference
Industrial front5.50-16Reference
Industrial rear12.4/11-28Reference
Length297 cmReference
Width162 cmReference
Height (steering wheel)149 cmReference
Clearance (front axle)50 cmReference
Clearance (rear axle)33 cmReference
Rear axle63 mmReference
Front tread132 cmReference
Rear tread121 to 193 cmReference
Gas Shipping1769 kgReference
Diesel Shipping1832 kgReference
Gas Operating1964 kgReference
Diesel Operating2027 kgReference
International Harvester 340 attachments
bladeReference
front-end loaderReference
backhoeReference
Capacities
Diameter27 cmReference
Speed949.45 meters/minReference
Attachment overview
BladeReference
International Wagner 110 loaderReference
International Wagner 140 loaderReference
BackhoeReference
International Wagner 65 Backhoe
Backhoe typeInternational Wagner 65 BackhoeReference
Transport height299 cmReference
Digging depth304 cmReference
Reach from pivot381 cmReference
Loading height243 cmReference
Swing Arc180°Reference
International Wagner 95 Backhoe
Backhoe typeInternational Wagner 95 BackhoeReference
Transport height355 cmReference
Digging depth403 cmReference
Reach from pivot477 cmReference
Loading height289 cmReference
Swing Arc180°Reference
International Wagner 1250 Backhoe
Backhoe typeInternational Wagner 1250 BackhoeReference
Transport height276 cmReference
Digging depth381 cmReference
Reach from pivot467 cmReference
Loading height243 cmReference
Swing Arc180°Reference
Speeds
With 12.4/11-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
