Tractor · 1971Unverified
International Harvester 354
International Harvester 354 — Utility tractor · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Max power
22.5 kW
Weight
1832 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Doncaster, EnglandReference
Original price was $4,200 in 1975Reference
Two-wheel driveReference
Power steeringReference
Differential mechanical dry disc brakesReference
Open operator station.Reference
Engine
International Harvester 2.3L 4-cyl gasolineReference
International Harvester 2.3L 4-cyl dieselReference
Engine26.1 kWReference
Drawbar (claimed)20.9 kWReference
Drawbar (tested)22.5 kWReference
International Harvester BC-144Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke86 x 102 mmReference
Power26.1 kWReference
Air cleanerdryReference
Rated RPM1875Reference
Starter volts12Reference
Oil capacity7.1 LReference
Coolant capacity10.4 LReference
International Harvester BD-144Reference
dieselReference
Power at rated engine speed24.5 kWReference
Max power22.5 kWReference
Power at rated engine speed24.3 kWReference
Max power20.7 kWReference
Transmission
8-speed sliding gearReference
Typesliding gearReference
Gears8 forward and 2 reverseReference
Oil capacity5.9 LReference
PTO & Hydraulics
PTO (claimed)23.9 kWReference
PTO (tested)24.5 kWReference
Hydraulic system11.4 LReference
Capacity11.4 LReference
Valves0 to 2Reference
Total flow22.7 lpmReference
Rear TypeIReference
Rear lift1180 kgReference
Rear PTOcontinuousReference
Rear PTO Type540Reference
Power at rated PTO speed24.0 kWReference
Power at rated PTO speed24.0 kWReference
Capacities
Fuel46.2 LReference
Dimensions
Wheelbase194 cmReference
Weight1832 kgReference
Front tire5.50-16Reference
Rear tire12.4-28Reference
Ag front5.50-16Reference
Ag rear12.4-28Reference
Length320 cmReference
Width162 cmReference
Height (steering wheel)144 cmReference
Operating weight1832 kgReference
Ballasted weight2687 kgReference
Clearance (front axle)45 cmReference
Front tread121 to 193 cmReference
Rear tread121 to 193 cmReference
354 Serial Numbers
1972990 (gasoline)Reference
19733013 (gasoline)Reference
19743844 (gasoline)Reference
19721468 (diesel)Reference
19732470 (diesel)Reference
19743019 (diesel)Reference
FAQ: How to read a serial number table.Reference
Test results
NTTL 733: diesel 8-speed 2WDReference
NTTL 1115: gasoline 8-speed 2WDReference
Diesel 8-speed 2WDMarch 3 - 23, 1960Link: Nebraska Tractor Test 733 fileReference
PTO performanceReference
Fuel use8.7 l/hourReference
Fuel use8.3 l/hourReference
Drawbar performanceReference
Fuel use9.5 l/hourReference
Gear 4L used for power test.Reference
Max pull2105 kgReference
Gear 2L used for pull test.Reference
Gasoline 8-speed 2WDNovember 1 - 22, 1972Link: Nebraska Tractor Test 1115 fileReference
Fuel use12.1 l/hourReference
Fuel use11.7 l/hourReference
Max pull2120 kgReference
Gear 1L used for pull test.Reference
Speeds
With 12.4-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
