Tractor · 1985Unverified
International Harvester 385
International Harvester 385 — Utility tractor · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
4869 to 4929 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Doncaster, EnglandReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post fixed ROPS. Cab available in Europe.Reference
Engine
International Harvester 2.5L 3-cyl dieselReference
Engine (gross)34.3 kWReference
Engine (net)32.1 kWReference
International Harvester D-155Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke98 x 111 mmReference
Power (net)32.1 kWReference
Power (gross)34.3 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM2200Reference
Idle RPM650-2400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.4 LReference
Coolant capacity11.4 LReference
Transmission
8-speed synchromeshReference
8-speed shuttleReference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
Clutch279.4mm cerametallic discReference
Oil capacity34.1 LReference
Four gears (1-4) in two ranges (low/high) plus reverse range.Reference
TypeshuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)26.1 kWReference
Hydraulic system34.1 LReference
Capacity34.1 LReference
Pressure172.4 barReference
Valves0 to 2Reference
Pump flow42.8 lpmReference
Steering flow9.5 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540Reference
Capacities
Fuel75.7 LReference
Dimensions
Utility Wheelbase200 cmReference
Low-profile Wheelbase198 cmReference
Weight4869 to 4929 poundsReference
Front tire6.00x16Reference
Utility Rear tire13.6x28Reference
Utility Standard tires (ag)Front: 6.00x16. Rear: 13.6x28Reference
Low-profile Standard tires (ag)Front: 9.00x10. Rear: 18.4x16.1Reference
Utility Length355 cmReference
Low-profile Length350 cmReference
Utility Width185 cmReference
Low-profile Width205 cmReference
Ground clearance35 cmReference
Clearance (drawbar)32 cmReference
Utility Front tread132 to 203 cmReference
Low-profile Front tread142 to 193 cmReference
Utility Rear tread132 to 193 cmReference
Low-profile Rear tread162 cmReference
Utility2235 kgReference
Low-profile2208 kgReference
Max rear axle4199 kgReference
Utility Steering wheel154 cmReference
Low-profile Steering wheel143 cmReference
385 Serial Number Location
Serial number plate on the right side of the 385 frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery volts12Reference
Battery AH93Reference
International Harvester 385 Height
Utility ROPS237 cmReference
Low-profile ROPS225 cmReference
Speeds
With 13.6-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
