Tractor · 1966Unverified
International Harvester 423
International Harvester 423 — Utility tractor · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
2015 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Neuss, GermanyReference
Two-wheel driveReference
Differential lockmechanical rearReference
Engine
International Harvester 2.5L 3-cyl dieselReference
Engine (gross)29.8 kWReference
Engine (net)28.3 kWReference
International Harvester D-155Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke98 x 111 mmReference
Power (net)28.3 kWReference
Power (gross)29.8 kWReference
Air cleanerdryReference
Compression16:1Reference
Rated RPM1900Reference
Starter volts12Reference
Oil capacity6.5 LReference
Coolant capacity13.0 LReference
Transmission
8-speed gearReference
12-speed creeperReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutch254mm dry discReference
Oil capacity34.5 LReference
TypecreeperReference
Gears12 forward and 3 reverseReference
Capacities
Fuel60.2 LReference
PTO & Hydraulics
Hydraulic system12.9 LReference
Capacity12.9 LReference
Rear TypeII/IReference
Rear lift1759 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase192 cmReference
Weight2015 kgReference
Front tire6.00-16Reference
Rear tire12.4/11-28Reference
Ag front6.00-16Reference
Ag rear12.4/11-28Reference
Ag front5.50-16Reference
Ag front7.50-16Reference
Ag rear9-32Reference
Ag rear12-28Reference
Ag rear9-36Reference
Ag rear11-32Reference
Ag rear11-36Reference
Length308 cmReference
Width162 cmReference
Height154 cmReference
Ground clearance38 cmReference
Front tread121 to 185 cmReference
Rear tread128 to 187 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
