Tractor · 1977Unverified
International Harvester 484
International Harvester 484 — 84 Series · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Max power
26.8 kW
Weight
5140 to 5200 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Doncaster, EnglandReference
Original price was $11,800 in 1984Reference
Two-wheel driveReference
Power steeringReference
Independent hydraulic wet disc brakesReference
Two-post fixed ROPS. Canopy optional.Reference
Engine
International Harvester 2.9L 3-cyl dieselReference
Engine37.3 kWReference
Drawbar (claimed)28.3 kWReference
Drawbar (tested)26.8 kWReference
International Harvester D-179Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke98 x 129 mmReference
Power37.3 kWReference
Air cleanerdryReference
Rated RPM2200Reference
Idle RPM700-2400Reference
Starter volts12Reference
Oil capacity6.4 LReference
Coolant capacity11.4 LReference
Power at rated engine speed31.6 kWReference
Max power26.8 kWReference
Transmission
8-speed syncromeshReference
TypesyncromeshReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
Oil capacity34.1 LReference
Four synchronized gears in high, low, and reverse ranges.Reference
PTO & Hydraulics
PTO (claimed)31.6 kWReference
PTO (tested)31.6 kWReference
Hydraulic system34.1 LReference
Typeopen centerReference
Capacity34.1 LReference
Valves0 to 2Reference
Total flow58.3 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift1406 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540Reference
Power at rated PTO speed31.2 kWReference
Capacities
Fuel75.7 LReference
Dimensions
Utility Wheelbase200 cmReference
Low-profile Wheelbase198 cmReference
Weight5140 to 5200 poundsReference
Front tire6.00-16Reference
Rear tire13.6-28Reference
Ag front6.00-16Reference
Ag rear13.6-28Reference
Utility Length339 cmReference
Low-profile Length351 cmReference
Utility Width178 cmReference
Low-profile Width199 cmReference
Utility Height (steering wheel)154 cmReference
Low-profile Height (steering wheel)143 cmReference
Utility Shipping weight2358 kgReference
Low-profile Shipping weight2331 kgReference
Utility Ground clearance40 cmReference
Low-profile Ground clearance27 cmReference
484 Serial Number Location
Serial number plate on the right side of the frame, above the front axle.Reference
484 Serial Numbers
1978501Reference
19791325Reference
19802754Reference
19815619Reference
1982unkReference
1983unkReference
19849165Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
Diesel 8-speed 2WDMay 22 - 31, 1979Link: Nebraska Tractor Test 1312 fileReference
PTO performanceReference
Fuel use11.0 l/hourReference
Fuel use10.6 l/hourReference
Drawbar performanceReference
Gear 1H used for power test.Reference
Max pull2494 kgReference
Gear 2L used for pull test.Reference
Speeds
With 13.6-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
