Industrial Tractor · 1974Unverified
International Harvester 500E
International Harvester 500E — Industrial Crawler tractor · 44 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Weight
10700 to 12670 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Industrial Crawler tractorReference
DrivecrawlerReference
Differential lockbull gearReference
Four-post ROPS canopy.Reference
Engine
International Harvester 2.5L 3-cyl dieselReference
Engine (net)32.8 kWReference
International Harvester D-155Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke98 x 111 mmReference
Power (net)32.8 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity7.6 LReference
Coolant capacity15.1 LReference
Transmission
3-speed torque converterReference
4-speed power shuttleReference
4-speed gearReference
Typetorque converterReference
Gears3 forward and reverseReference
Typepower shuttleReference
Gears4 forward and reverseReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutch279.4mm dry discReference
Capacities
Fuel104.1 LReference
PTO & Hydraulics
Hydraulic system20.8 LReference
Typeopen centerReference
Capacity20.8 LReference
Pump flow45.4 lpmReference
Pump flow64.3 lpmReference
Pump flow102.2 lpmReference
Dimensions
Weight10700 to 12670 poundsReference
12-inch tracksReference
Length258 cmReference
Width162 cmReference
Height (steering wheel)162 cmReference
Height (ROPS)228 cmReference
Shipping weight4853 kgReference
Shipping weight5747 kgReference
Gauge127 cmReference
International Harvester 500E attachments
bladeReference
front-end loaderReference
Electrical
Charging systemalternatorReference
Batteries2Reference
Battery volts6Reference
Battery AH135Reference
Attachment overview
BladeReference
Front-end loaderReference
International Harvester 500E Tracks
Width30 cmReference
Length on ground172 cmReference
Area on ground1.1 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
