Tractor · 1975Unverified
International Harvester 533
International Harvester 533 — 33 Series · 44 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Weight
4938 to 6107 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Neuss, GermanyReference
Two- or four-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Open operator station. Cab optional.Reference
Variants
533utilityReference
533VvineyardReference
Engine
International Harvester 2.5L 3-cyl dieselReference
Engine33.1 kWReference
International Harvester D-155Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke98 x 111 mmReference
Power33.1 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
Torque159.9 NmReference
Torque RPM1600Reference
Starter volts12Reference
Oil capacity6.5 LReference
Coolant capacity3.5 LReference
Transmission
8-speedReference
16-speedReference
16-speed creeperReference
Gears8 forward and 4 reverseReference
Four gears (1-4) in two ranges, plus reverse range.Reference
TransmissionSynchronReference
Gears16 forward and 8 reverseReference
TypecreeperReference
Capacities
Fuel60.0 LReference
PTO & Hydraulics
Hydraulic system12.1 LReference
Typeopen centerReference
Capacity12.1 LReference
Pump flow32.6 lpmReference
Rear TypeIIReference
Rear lift1800 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
2WD Wheelbase207 cmReference
4WD Wheelbase202 cmReference
Weight4938 to 6107 poundsReference
Front tire6.50-16Reference
2WD Rear tire14.9R28Reference
2WD Standard tires (ag)Front: 6.50-16. Rear: 14.9R28Reference
4WD Standard tires (ag)Front: 10.5-18. Rear: 14.9R28Reference
Length342 cmReference
Width164 cmReference
Height (cab)239 cmReference
2WD Clearance (front axle)52 cmReference
4WD Clearance (front axle)32 cmReference
2WD Front tread122 to 176 cmReference
4WD Front tread137 to 162 cmReference
Rear tread142 to 192 cmReference
2WD Open2239 kgReference
4WD Open2530 kgReference
2WD Cab2479 kgReference
4WD Cab2770 kgReference
Electrical
Charging systemalternatorReference
Charging amps33Reference
Battery volts12Reference
Speeds
With 14.9/13-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
