Tractor · 1958Unverified
International Harvester 560
International Harvester 560 — Standard-tread tractor · 59 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
59 hp
Max power
39.6 kW
Weight
6563 to 6785 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Standard-tread tractorReference
Total built65,982Reference
Original price was $5,500 in 1963Reference
Two-wheel driveReference
SteeringmanualReference
Steeringhydrostatic power optionalReference
Independent mechanical disc brakesReference
Open operator station.Reference
Variants
Farmall 560row-cropReference
Hi-Clearhigh-cropReference
Engine
International Harvester 4.6L 6-cyl dieselReference
International Harvester 4.3L 6-cyl gasolineReference
International Harvester 4.3L 6-cyl LP gasReference
Engine54.1 kWReference
Drawbar (claimed)40.9 kWReference
Plows5Reference
Drawbar (tested)39.6 kWReference
Belt (tested)44.8 kWReference
International Harvester D-282Reference
dieselReference
6-cylinderReference
liquid-cooled vertical I-headReference
Displacement4.6 LReference
Bore/Stroke94 x 112 mmReference
Power54.1 kWReference
Air cleaneroil bathReference
Compression18.2:1Reference
Rated RPM1800Reference
Torque295.6 NmReference
Torque RPM1400Reference
Firing order1-5-3-6-2-4Reference
Oil capacity8.5 LReference
Coolant capacity21.9 LReference
Exhaust valve clearance0.686 mmReference
International Harvester C-263Reference
gasolineReference
Displacement4.3 LReference
Bore/Stroke90 x 112 mmReference
Compression7.2:1Reference
Torque291.5 NmReference
Torque RPM1050Reference
Coolant capacity18.5 LReference
LP gasReference
Compression8.75:1Reference
Torque287.5 NmReference
Torque RPM1100Reference
Coolant capacity19.0 LReference
Power at rated engine speed44.4 kWReference
Max power39.6 kWReference
Power at rated engine speed47.0 kWReference
Max power38.0 kWReference
Belt power (max)44.8 kWReference
Max power32.8 kWReference
Transmission
5-speedReference
10-speedReference
Transmissionsliding gearReference
Gears5 forward and 1 reverseReference
Oil capacity60.6 LReference
TransmissionTorque AmplifierReference
Gears10 forward and 2 reverseReference
The Torque Amplifier (TA) provides a clutchless powershift between direct drive (DD) and the lower TA speed.Reference
PTO & Hydraulics
PTO (claimed)44.4 kWReference
PTO (tested)47.0 kWReference
Hydraulic system60.6 LReference
Capacity60.6 LReference
Valves2Reference
Pump flow45.4 lpmReference
Total flow45.4 lpmReference
Total flow64.3 lpmReference
Steering flow9.5 lpmReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Capacities
Fuel124.9 LReference
Fuel141.9 LReference
Diameter27 cmReference
Width19 cmReference
Dimensions
Wheelbase217 cmReference
Weight6563 to 6785 poundsReference
Front tire6.50-18Reference
Rear tire16.9/14-30Reference
Ag front6.50-18Reference
Ag rear16.9/14-30Reference
Ag front7.50-18Reference
Industrial rear16.9/14-26Reference
Industrial rear23.1/18-26Reference
Length370 cmReference
Width182 cmReference
Width218 cmReference
Height (steering wheel)218 cmReference
Ground clearance38 cmReference
Clearance (rear axle)40 cmReference
Bar rear axle69 mmReference
Operating2976 kgReference
Operating3077 kgReference
Ballasted4291 kgReference
International Harvester 560 attachments
front-end loaderReference
backhoeReference
560 Serial Number Location
Clutch housing, right sideReference
560 Serial Numbers
1958501Reference
19591210Reference
19603103Reference
19614032Reference
19624944Reference
19635598Reference
FAQ: How to read a serial number table.Reference
Attachment overview
Front-end loaderReference
BackhoeReference
IH-Wagner 95 Backhoe
Backhoe typeIH-Wagner 95 BackhoeReference
Digging depth33 cmReference
Reach from pivot39 cmReference
Loading height24 cmReference
Test results
NTTL 669: diesel Torque Amplifier 2WDReference
NTTL 671: gasoline Torque Amplifier 2WDReference
NTTL 675: LP gas Torque Amplifier 2WDReference
Diesel Torque Amplifier 2WDSeptember 18 - 25, 1958Link: Nebraska Tractor Test 669 fileReference
PTO performanceReference
Fuel use15.5 l/hourReference
Drawbar performanceReference
Gear 3 used for power test.Reference
Max pull3332 kgReference
Gear 1 used for pull test.Reference
Gasoline Torque Amplifier 2WDSeptember 24 - October 6, 1958Link: Nebraska Tractor Test 671 fileReference
Fuel use18.9 l/hourReference
Max pull3441 kgReference
Gear 1-TA used for pull test.Reference
LP gas Torque Amplifier 2WDOctober 8 - 20, 1958Link: Nebraska Tractor Test 675 fileReference
Belt fuel use (max)24.6 l/hourReference
Fuel use19.3 l/hourReference
Max pull3412 kgReference
Speeds
With 16.9/14-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
