Tractor · 1977Unverified
International Harvester 584
International Harvester 584 — 84 Series · 53 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
53 hp
Max power
34.8 kW
Weight
5580 to 6685 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Doncaster, EnglandReference
Original price was $18,850 in 1984Reference
Two- or four-wheel driveReference
Power steeringReference
Independent hydraulic wet disc brakesReference
ROPS canopy or cab optional.Reference
Engine
International Harvester 3.4L 4-cyl dieselReference
Engine44.7 kWReference
Drawbar (claimed)35.3 kWReference
Drawbar (tested)34.8 kWReference
International Harvester D-206Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke98 x 111 mmReference
Power44.7 kWReference
Air cleanerdryReference
Rated RPM2300Reference
Starter volts12Reference
Oil capacity8.3 LReference
Coolant capacity13.6 LReference
Power at rated engine speed39.2 kWReference
Max power34.8 kWReference
Transmission
8-speed syncromeshReference
TypesyncromeshReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
Oil capacity34.1 LReference
Four synchronized gears in high, low, and reverse ranges.Reference
PTO & Hydraulics
PTO (claimed)39.1 kWReference
PTO (tested)39.2 kWReference
Hydraulic system34.1 LReference
Typeopen centerReference
Capacity34.1 LReference
Valves1 or 2Reference
Total flow60.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift1632 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540Reference
Power at rated PTO speed38.0 kWReference
Capacities
Fuel75.7 LReference
Dimensions
Utility Wheelbase214 cmReference
Row-crop Wheelbase214 cmReference
4WD Wheelbase216 cmReference
Low-profile Wheelbase212 cmReference
Weight5580 to 6685 poundsReference
Front tire7.50-16Reference
Rear tire16.9-30Reference
Ag front7.50-16Reference
Ag rear16.9-30Reference
Utility Length360 cmReference
Row-crop Length353 cmReference
4WD Length371 cmReference
Low-profile Length360 cmReference
Utility Width187 cmReference
Row-crop Width190 cmReference
4WD Width187 cmReference
Low-profile Width199 cmReference
Utility Ground clearance45 cmReference
Row-crop Ground clearance45 cmReference
4WD Ground clearance45 cmReference
Low-profile Ground clearance27 cmReference
Bar rear axle69 mmReference
Utility Shipping2558 kgReference
Row-crop Shipping2707 kgReference
4WD Shipping3032 kgReference
Low-profile Shipping2531 kgReference
Operating3023 kgReference
Ballasted4014 kgReference
Utility Steering wheel160 cmReference
Row-crop Steering wheel160 cmReference
4WD Steering wheel160 cmReference
Low-profile Steering wheel143 cmReference
584 Serial Number Location
Front axle support on right side of tractor.Reference
584 Serial Numbers
1978501Reference
19792120Reference
19803944Reference
19815766Reference
19827033Reference
19838348Reference
19849215Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging amps45Reference
Battery volts12Reference
International Harvester 584 Height
ROPS254 cmReference
Test results
Diesel 8-speed 2WDMay 24 - June 11, 1979Link: Nebraska Tractor Test 1313 fileReference
PTO performanceReference
Fuel use13.2 l/hourReference
Fuel use12.5 l/hourReference
Drawbar performanceReference
Gear 1H used for power test.Reference
Max pull3111 kgReference
Gear 2L used for pull test.Reference
Speeds
With 16.9-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
