Tractor · 1972Unverified
International Harvester 734
International Harvester 734 — Row-Crop tractor · 73 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
73 hp
Weight
7477 to 8245 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
SteeringmanualReference
SteeringpowerReference
Disc brakesReference
Cab standard with optional heater.Reference
Engine
International Harvester 3.9L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine (gross)54.4 kWReference
Engine (net)49.3 kWReference
International Harvester D-239Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 129 mmReference
Power (net)49.3 kWReference
Power (gross)54.4 kWReference
Fuel systemdirect injectionReference
Compression16:1Reference
Rated RPM2200Reference
Torque251.1 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity9.0 LReference
Coolant capacity19.5 LReference
Transmission
8-speedReference
12-speedReference
Gears8 forward and 4 reverseReference
Clutch280mm dry discReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)46.0 kWReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase212 cmReference
Weight7477 to 8245 poundsReference
Front tire7.50x16Reference
2WD Rear tire16.9/14x34Reference
2WD Standard tires (ag)Front: 7.50x16. Rear: 16.9/14x34Reference
4WD Standard tires (ag)Front: 11.2/10x24. Rear: 16.9/14x34Reference
2WD Length334 cmReference
4WD Length346 cmReference
Width188 cmReference
Height (steering wheel)165 cmReference
2WD Weight3391 kgReference
4WD Weight3739 kgReference
2WD Front tread131 to 178 cmReference
4WD Front tread150 cmReference
Rear tread146 to 196 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
