Tractor · 1981Unverified
International Harvester 833
International Harvester 833 — 33 Series · 67 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
67 hp
Weight
2914 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Neuss, GermanyReference
Four-wheel driveReference
Variants
833utilityReference
833EnarrowReference
Engine
International Harvester 3.9L 4-cyl dieselReference
Engine50.0 kWReference
International Harvester D-239Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 129 mmReference
Power50.0 kWReference
Fuel systemdirect injectionReference
Rated RPM2300Reference
Torque235.0 NmReference
Torque RPM1500Reference
Starter volts12Reference
Oil capacity9.0 LReference
Transmission
8-speedReference
16-speedReference
16-speed creeperReference
Gears8 forward and 4 reverseReference
Oil capacity34.5 LReference
Four gears (1-4) in two ranges, plus reverse range.Reference
TransmissionSynchronReference
Gears16 forward and 8 reverseReference
TypecreeperReference
Capacities
Fuel65.1 LReference
PTO & Hydraulics
Hydraulic system12.1 LReference
Capacity12.1 LReference
Pressure175.0 barReference
Pump flow60.0 lpmReference
Rear TypeIIReference
Controlposition control and upper-link draft sensingReference
Rear lift2200 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase215 cmReference
Weight2914 kgReference
Front tire10.5-18Reference
Rear tire14.9R30Reference
Standard tires (ag)Front: 10.5-18. Rear: 14.9R30Reference
Length357 cmReference
Width197 cmReference
Height (cab)247 cmReference
Ground clearance30 cmReference
Front tread137 to 162 cmReference
Rear tread127 to 193 cmReference
Electrical
Charging systemalternatorReference
Charging amps33Reference
Battery volts12Reference
Speeds
With 16.9R30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
