Tractor · 1979Unverified
International Harvester 884
International Harvester 884 — 84 Series · 73 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
73 hp
Max power
47.7 kW
Weight
5905 to 7223 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Original price was $25,600 in 1984Reference
Two- or four-wheel driveReference
Power steeringReference
Independent hydraulic wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
International Harvester 4.4L 4-cyl dieselReference
Drawbar (claimed)48.8 kWReference
Drawbar (tested)47.7 kWReference
International Harvester D-268Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke100 x 140 mmReference
Air cleanerdryReference
Rated RPM2400Reference
Starter volts12Reference
Oil capacity8.3 LReference
Coolant capacity13.6 LReference
Power at rated engine speed54.4 kWReference
Max power47.7 kWReference
Transmission
16-speed two-speed power shiftReference
TransmissionTorque AmplifierReference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference
Clutchdry discReference
Oil capacity34.1 LReference
The basic transmission provides four gears in each of high, low, and reverse ranges. The Torque Amplifier (TA) provides an on-the-move clutchless power shift from direct drive (DD) to the lower TA speed.Reference
PTO & Hydraulics
PTO (claimed)54.4 kWReference
PTO (tested)54.4 kWReference
Hydraulic system34.1 LReference
Typeopen centerReference
Capacity34.1 LReference
Valves1 or 2Reference
Total flow58.3 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift1632 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Power at rated PTO speed52.0 kWReference
Capacities
Fuel75.7 LReference
Dimensions
Utility Wheelbase223 cmReference
Row-crop Wheelbase214 cmReference
4WD Wheelbase216 cmReference
Low-profile Wheelbase212 cmReference
Weight5905 to 7223 poundsReference
Front tire7.50-18Reference
Rear tire18.4-30Reference
Ag front7.50-18Reference
Ag rear18.4-30 (utility)Reference
Ag rear15.5-38 (row-crop)Reference
Utility Length360 cmReference
Row-crop Length353 cmReference
4WD Length376 cmReference
Low-profile Length360 cmReference
Utility Width190 cmReference
Row-crop Width187 cmReference
4WD Width187 cmReference
Low-profile Width199 cmReference
Utility Ground clearance45 cmReference
Row-crop Ground clearance50 cmReference
4WD Ground clearance45 cmReference
Low-profile Ground clearance27 cmReference
Bar rear axle69 mmReference
Utility Shipping2751 kgReference
Row-crop Shipping2864 kgReference
4WD Shipping3276 kgReference
Low-profile Shipping2678 kgReference
Ballasted4604 kgReference
Utility Steering wheel162 cmReference
Row-crop Steering wheel165 cmReference
4WD Steering wheel162 cmReference
Low-profile Steering wheel143 cmReference
884 Serial Numbers
Location:Serial number plate on the right side of IH 884 frame, above the front axle.Reference
1979501Reference
1980710Reference
19815575Reference
19826738Reference
19838238Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging amps45Reference
Battery volts12Reference
Test results
Diesel Torque Amplifier 2WDNovember 5 - 13, 1980Link: Nebraska Tractor Test 1376 fileReference
PTO performanceReference
Fuel use17.8 l/hourReference
Fuel use16.7 l/hourReference
Drawbar performanceReference
Gear 2H-TA used for power test.Reference
Max pull3681 kgReference
Gear 3L-TA used for pull test.Reference
Speeds
With 18.4-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
