Tractor · 1977Unverified
International Harvester 955
International Harvester 955 — Row-Crop tractor · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Weight
9459 to 10297 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Row-Crop tractorReference
Built in Neuss, GermanyReference
Two- or four-wheel driveReference
Engine
International Harvester 5.1L 6-cyl dieselReference
International Harvester 5.9L 6-cyl dieselReference
Fuel tank140.0 LReference
Engine67.1 kWReference
International HarvesterReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.1 LReference
Bore/Stroke98 x 111 mmReference
Power67.1 kWReference
Rated RPM2300Reference
Torque97.6 NmReference
Torque RPM1500Reference
Starter volts12Reference
Displacement5.9 LReference
Bore/Stroke98 x 129 mmReference
Rated RPM2200Reference
Torque101.7 NmReference
Torque RPM1400Reference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Pump flow36.0 lpmReference
Rear lift4325 kgReference
Rear PTO Type540, 1000Reference
Dimensions
Wheelbase262 cmReference
Weight9459 to 10297 poundsReference
Front tire7.50-18Reference
Rear tire18.4-34Reference
2WD Ag front7.50-18Reference
4WD Ag front12.4-28Reference
Ag rear18.4-34Reference
Length425 cmReference
Height277 cmReference
2WD Weight4290 kgReference
4WD Weight4670 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
