Tractor · 1981Unverified

International Harvester 986B

International Harvester 986B — 86B Series · 115 hp. Reference specifications; pending source verification.

The International Harvester 986B is a tractor model, rated at 115 hp, a mid-range figure for its class. Built from 1981 to 1982, it features a 6-cylinder turbocharged diesel liquid-cooled engine and two-wheel drive with a powershift transmission. The operating weight of the 986B is listed as 5640 kg, with a suitable operating range of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
115 hp
Weight
5640 kg

Catalogue coverage

Variants represented
2
Richest spec table
43 rows
Recorded power
115 hp
Recorded weight
5640 kg
Transmissions
16-speed two-speed power shift
Production years
1981-1982
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerInternational HarvesterReference
Row-Crop tractorReference
Built in Geelong, AustraliaReference
Total built328Reference
Two-wheel driveReference
Cab standard.Reference

Engine

International Harvester 5.9L 6-cyl dieselReference
Engine99.2 kWReference
Drawbar (claimed)76.8 kWReference
International Harvester DT-358Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke98 x 129 mmReference
Power99.2 kWReference
Fuel systemdirect injectionReference
Rated RPM2500Reference
Torque450.1 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference

Transmission

16-speed two-speed power shiftReference
TransmissionInternational Harvester Torque AmplifierReference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference

PTO & Hydraulics

PTO (claimed)85.8 kWReference
Hydraulic system85.2 LReference
Capacity85.2 LReference
Rear valves2Reference
Rear TypeIIIReference
Rear lift (at ends)2844 kgReference
Rear PTO Type540/1000Reference

Dimensions

Weight5640 kgReference
Front tire11.00-16Reference
Rear tire23.1-34Reference
Standard tires (ag)Front: 11.00-16. Rear: 23.1-34Reference
Length405 cmReference
Width258 cmReference
Shipping weight5640 kgReference
Ground clearance55 cmReference

Electrical

GroundnegativeReference
Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
