Tractor · 1962Unverified
International Harvester A-414
International Harvester A-414 · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
1764 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Built in Geelong, AustraliaReference
Original price was AUP 1,095 in 1964Reference
The McCormick A-414 was the Australian version of the British B-414 utility tractor.Reference
Two-wheel driveReference
Differential lockmechanical rearReference
Differential mechanical disc brakesReference
Open operator station.Reference
Variants
HI-CLEARhigh-crop optionReference
Engine
International Harvester 2.5L 4-cyl dieselReference
Engine29.8 kWReference
Drawbar (claimed)24.7 kWReference
Belt (claimed)26.8 kWReference
International Harvester AD-154Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke89 x 102 mmReference
Power29.8 kWReference
Compression22:1Reference
Rated RPM2000Reference
Torque155.9 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity4.4 LReference
Coolant capacity9.8 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Oil capacity15.6 LReference
PTO & Hydraulics
PTO (claimed)27.4 kWReference
Hydraulic system9.8 LReference
Typeopen centerReference
Capacity9.8 LReference
Pressure151.7 barReference
Valves1Reference
Rear PTOtransmissionReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM545@2000Reference
Engine RPM745@2000Reference
Capacities
Fuel41.4 LReference
Dimensions
Weight1764 kgReference
Front tire6.00-16Reference
Rear tire13.6-28Reference
Ag front6.00-16Reference
Ag rear13.6-28Reference
Ag front7.50-16Reference
Ag rear14.9-24Reference
Ag rear14.9-28Reference
Ag rear16.9-28Reference
Ag rear12.4x38 (HI-CLEAR)Reference
Ag rear13.6x38 (HI-CLEAR)Reference
Length290 cmReference
Width157 cmReference
Height156 cmReference
Operating weight1764 kgReference
Ballasted weight2209 kgReference
Ground clearance43 cmReference
International Harvester A-414 attachments
front-end loaderReference
Speeds
With 13.6-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
