Tractor · 1966Unverified
International Harvester B-276
International Harvester B-276 — Utility tractor · 38 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
38 hp
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Bradford, EnglandReference
Two-wheel driveReference
SteeringmechanicalReference
Open operator station.Reference
Engine
International Harvester 2.4L 4-cyl dieselReference
International Harvester 2.3L 4-cyl gasolineReference
Engine28.0 kWReference
International Harvester BD-144Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke86 x 102 mmReference
Power28.0 kWReference
Rated RPM1875Reference
Torque149.2 NmReference
Torque RPM1400Reference
Starter typeelectricReference
International Harvester BC144Reference
gasolineReference
Displacement2.3 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
