Tractor · 1959Unverified
International Harvester D-440
International Harvester D-440 — D Series · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
2080 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Neuss, GermanyReference
Total built1,787Reference
Two-wheel driveReference
Open operator station.Reference
Engine
International Harvester 2.2L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine29.8 kWReference
International Harvester DD-132SReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke83 x 102 mmReference
Power29.8 kWReference
Compression19:1Reference
Rated RPM1900Reference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity13.7 LReference
Transmission
8-speedReference
TransmissionAgriomaticReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase187 cmReference
Weight2080 kgReference
Front tire6.00-16Reference
Rear tire11-28Reference
Ag front6.00-16Reference
Ag rear11-28Reference
Ag rear13-30Reference
Ag rear11-36Reference
Length288 cmReference
Width173 cmReference
Height165 cmReference
Speeds
With 11-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
