Tractor · 1962Unverified
International Harvester F-270
International Harvester F-270 — Utility tractor · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
1856 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Saint Dizier, FranceReference
Two-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
International Harvester 2.2L 4-cyl dieselReference
Fuel tank43.1 LReference
Engine29.8 kWReference
International Harvester FD 136 MReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke84 x 102 mmReference
Power29.8 kWReference
Rated RPM2000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.2 LReference
Coolant capacity12.3 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
Oil capacity35.5 LReference
PTO & Hydraulics
Rear TypeIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase216 cmReference
Weight1856 kgReference
Front tire4.50x16Reference
Rear tire10x36Reference
Ag front4.50x16Reference
Ag rear10x36Reference
Ag front6.00x16Reference
Ag rear11x16Reference
Length323 cmReference
Width223 cmReference
Height130 cmReference
Ground clearance43 cmReference
Front tread124 to 189 cmReference
Rear tread127 to 189 cmReference
Speeds
With 10x36 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
