Tractor · 1924Unverified

International Harvester Farmall

International Harvester Farmall — Row-Crop tractor · 13 hp. Reference specifications; pending source verification.

The International Harvester Farmall is a tractor with a rated power of 13 hp, situated at the lighter end of its class. Manufactured from 1924 to 1932, it features a 4-cylinder petrol liquid-cooled engine paired with two-wheel drive, a 3-speed gearbox and an operating weight of 1814 kg. This tractor is capable of supporting operations on up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
13 hp
Max power
9.9 kW
Weight
1814 kg

Catalogue coverage

Variants represented
2
Richest spec table
63 rows
Recorded power
13 hp
Recorded weight
1814 kg
Transmissions
3-speed
Production years
1924-1932
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerInternational HarvesterReference
Row-Crop tractorReference
FactoriesChicago, Illinois, USAReference
FactoriesRock Island, Illinois, USAReference
Total built134,650Reference
Originally named simply the "Farmall", this original model later became unofficially known as the "Regular" after the improved Farmall F-20 was introduced. The Farmall was the first successful row-crop tractor design and its design dominated North American tractors for the following fifty years.Reference
Two-wheel driveReference
Steeringmanual with automatic engagement of turning brakesReference
Open operator's seatReference

Variants

Fairwaywide steel wheels for turfReference

Engine

International Harvester 3.6L 4-cyl gasolineReference
Fuel tank49.2 LReference
Aux. fuel3.3 LReference
Plows2Reference
Drawbar (tested)9.9 kWReference
Belt (tested)15.0 kWReference
International HarvesterReference
gasolineReference
4-cylinderReference
liquid-cooled verticalReference
Displacement3.6 LReference
Bore/Stroke95 x 127 mmReference
Air cleaneroil bath and fiberReference
Rated RPM1200Reference
Starter typehand crankReference
Coolant capacity34.1 LReference
Belt power (max)15.0 kWReference
Max power9.9 kWReference

Transmission

3-speedReference
Gears3 forward and 1 reverseReference

PTO & Hydraulics

Rear PTOtransmissionReference
Rear PTO Type535Reference

Dimensions

Weight1814 kgReference
Front tire25x4Reference
Rear tire40x6Reference
Ag front25x4 steelReference
Ag rear40x6 steelReference
Lawn/turf front25x8 steel (Fairway)Reference
Lawn/turf rear40x16 steel (Fairway)Reference
Length345 cmReference
Width218 cmReference
Height170 cmReference

Farmall Serial Numbers

Location:Tractor tool box.Reference
1924501Reference
1925701Reference
19261539Reference
19275969Reference
192815471Reference
192940370Reference
193075691Reference
1931117784Reference
1932131872Reference
Final134952Reference
FAQ: How to read a serial number table.Reference

Capacities

Diameter35 cmReference
Width16 cmReference
RPM693Reference

Test results

Gasoline 3-speed 2WDSeptember 14 - 19, 1925Link: Nebraska Tractor Test 117 fileReference
Belt fuel use (max)7.9 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1236 kgReference
Gear 1 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
