Tractor · 1940Unverified
International Harvester FG
International Harvester FG — Row-Crop tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1750 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Row-Crop tractorReference
Built in Neuss, GermanyReference
Total built1,593 totalReference
Total built1,543 FGReference
Total built50 FG-D-2Reference
Two-wheel driveReference
Manual steeringReference
Open operator stationReference
Variants
FG-D-2MWM diesel engineReference
Engine
International Harvester 2.0L 4-cyl keroseneReference
MWM 2.4L 2-cyl dieselReference
Engine14.9 kWReference
International HarvesterReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke80 x 102 mmReference
Power14.9 kWReference
Rated RPM1650Reference
Starter typehand-crankReference
MWM KD-415ZReference
dieselReference
2-cylinderReference
Displacement2.4 LReference
Bore/Stroke100 x 150 mmReference
Rated RPM1500Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Dimensions
Wheelbase195 cmReference
Weight1750 kgReference
Front tire5.00x16Reference
Rear tire9.00x40Reference
Ag front5.00x16Reference
Ag rear9.00x40Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
