Tractor · 1913Unverified
International Harvester Mogul 15-30
International Harvester Mogul 15-30 — Standard-tread tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
6985 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Standard-tread tractorReference
Built in Chicago, Illinois, USAReference
Total built528Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open station with steel canopy.Reference
Engine
International Harvester 1-cyl keroseneReference
Fuel tank170.3 LReference
Drawbar (claimed)11.2 kWReference
Belt (claimed)22.4 kWReference
International HarvesterReference
keroseneReference
1-cylinderReference
liquid-cooledReference
Rated RPM380Reference
Starter typegas pony motorReference
Transmission
1-speedReference
Gears1 forward and reverseReference
Dimensions
Weight6985 kgReference
Front tire44x10Reference
Rear tire73x24Reference
Ag front44x10 (steel)Reference
Ag rear73x24 (steel)Reference
Length528 cmReference
Width261 cmReference
Height302 cmReference
Mogul 15-30 Serial Numbers
1913C1313Reference
1914C1750Reference
1915C1791Reference
FinalC1840Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter71 cmReference
Width27 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
