The International Harvester Mogul 45 is a tractor model with a rated power of 45 hp, categorised as a lighter model within its class. Production of the Mogul 45 spanned from 1911 to 1912. The tractor is powered by a 2-cylinder petrol liquid-cooled engine and features a two-wheel drive system with a 1-speed gearbox, with an operating weight of 8391 kg. It is suited to operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
8391 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
45 hp
Recorded weight
8391 kg
Transmissions
1-speed gear
Production years
1911-1912
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Built in Chicago, Illinois, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator platform with canopy.Reference
Engine
International Harvester 27.9L 2-cyl gasolineReference
Belt (claimed)33.6 kWReference
International HarvesterReference
gasolineReference
2-cylinderReference
liquid-cooled opposed-twinReference
Displacement27.9 LReference
Bore/Stroke241 x 305 mmReference
Rated RPM375Reference
Operating RPM200-375Reference
Transmission
1-speed gearReference
TypegearReference
Gears1 forward and reverseReference
The Mogul transmission was geared forward, but used a friction band to provide reverse.Reference
Dimensions
Wheelbase335 cmReference
Weight8391 kgReference
Front tire40x10Reference
Rear tire72x24Reference
Ag front40x10 steelReference
Ag rear72x24 steelReference
Length548 cmReference
Width279 cmReference
Height (exhaust)299 cmReference
Rear axle127 mmReference
Capacities
Diameter71 cmReference
Width25 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
