Tractor · 1940Unverified
International Harvester T-9
International Harvester T-9 — Agricultural Crawler tractor · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Max power
30.3 kW
Weight
9490 to 10700 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Agricultural Crawler tractorReference
Built in Melrose Park, Illinois, USAReference
Total built59,800Reference
DrivecrawlerReference
Open operator station.Reference
Variants
T-9gasolineReference
TD-9dieselReference
Engine
International Harvester 5.5L 4-cyl gasolineReference
Fuel tank117.3 LReference
Drawbar (claimed)23.9 kWReference
Belt (claimed)30.6 kWReference
Drawbar (tested)30.3 kWReference
Belt (tested)34.6 kWReference
International HarvesterReference
gasolineReference
4-cylinderReference
liquid-cooled vertical I-headReference
Displacement5.5 LReference
Bore/Stroke112 x 140 mmReference
Rated RPM1400Reference
Oil capacity10.4 LReference
Coolant capacity45.4 LReference
Belt power (max)34.6 kWReference
Max power30.3 kWReference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
Dimensions
Weight9490 to 10700 poundsReference
TracksReference
Length289 cmReference
Width190 cmReference
Height168 cmReference
Shipping4304 kgReference
Shipping4474 kgReference
Operating4853 kgReference
T-9 Serial Number Location
Serial number plate on the upper-left of the dash.Reference
T-9 Serial Numbers
1940501Reference
19412174Reference
19424164Reference
19438664Reference
194411912Reference
194518247Reference
194623692Reference
194726289Reference
194819512Reference
194932973Reference
195036927Reference
195140398Reference
195244710Reference
195347848Reference
195452599Reference
195556208Reference
195658819Reference
FAQ: How to read a serial number table.Reference
Test results
Gasoline 5-speed crawlerMay 27 - June 18, 1941Link: Nebraska Tractor Test 372 fileReference
Belt fuel use (max)14.8 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull4476 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
