Tractor · 1939Unverified

International Harvester TD-14

International Harvester TD-14 — Agricultural Crawler tractor · 54 hp. Reference specifications; pending source verification.

The International Harvester TD-14 is a tractor with a rated output of 54 hp, featuring a compact design. It was manufactured from 1939 to 1958, and is equipped with a 4-cylinder diesel liquid-cooled engine. This engine drives the tractor's tracked undercarriage through a 6-speed gearbox, with a listed weight of 7938 kg. The TD-14 is suited to jobs involving up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
54 hp
Max power
38.6 kW
Weight
7938 kg

Catalogue coverage

Variants represented
2
Richest spec table
68 rows
Recorded power
54 hp
Recorded weight
7938 kg
Transmissions
6-speed gear
Production years
1939-1958
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerInternational HarvesterReference
Agricultural Crawler tractorReference
Built in Melrose Park, Illinois, USAReference
Total built26,259Reference
DrivecrawlerReference
Open operator station.Reference

Variants

T-14gas crawlerReference
TD-14diesel crawlerReference

Engine

International Harvester 7.6L 4-cyl dieselReference
Fuel tank170.3 LReference
Aux. fuel5.3 LReference
Drawbar (claimed)39.9 kWReference
Belt (claimed)47.7 kWReference
Drawbar (tested)38.6 kWReference
Belt (tested)45.9 kWReference
International HarvesterReference
dieselReference
4-cylinderReference
liquid-cooled vertical I-headReference
Displacement7.6 LReference
Bore/Stroke121 x 165 mmReference
Air cleaneroil bathReference
Rated RPM1350Reference
Starter typegasoline-startReference
Oil capacity15.1 LReference
Coolant capacity75.7 LReference
Belt power (max)45.9 kWReference
Max power38.6 kWReference

Transmission

6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Oil capacity22.7 LReference

Dimensions

Weight7938 kgReference
16-inch tracksReference
Length340 cmReference
Width187 cmReference
Width233 cmReference
Height (hood)187 cmReference
Height (exhaust)186 cmReference
Ground clearance29 cmReference
Gauge142 cmReference
Gauge187 cmReference

TD-14 Serial Numbers

Location:Serial number plate on the upper-left of the TD-14 dashboard.Reference
1939TDF501Reference
1940TDF575Reference
1941TDF2045Reference
1942TDF3856Reference
1943TDF3580Reference
1944TDF7451Reference
1945TDF10728Reference
1946TDF12704Reference
1947TDF14437Reference
1948TDF21027Reference
1949TDF23357Reference
FinalTDF26759Reference
FAQ: How to read a serial number table.Reference

Capacities

Diameter31 cmReference
Width27 cmReference
RPM844Reference
Speed824.79 meters/minReference

International Harvester TD-14 Tracks

Width40 cmReference

Test results

Diesel 6-speed crawlerMay 6 - 31, 1940Link: Nebraska Tractor Test 343 fileReference
Belt fuel use (max)14.8 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull6090 kgReference
Gear 1 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
