Industrial Tractor · 1972Unverified
International Harvester TD-15C
International Harvester TD-15C — Industrial Crawler tractor · 140 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
140 hp
Weight
11113 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Industrial Crawler tractorReference
DrivecrawlerReference
Four-post ROPS.Reference
Variants
TD-15CbulldozerReference
175Ccrawler-loaderReference
Engine
International Harvester 7.6L 6-cyl dieselReference
Fuel tank302.8 LReference
Engine104.4 kWReference
International Harvester DT-466Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.6 LReference
Bore/Stroke109 x 136 mmReference
Power104.4 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Rated RPM2400Reference
Starter typeelectricReference
Oil capacity17.0 LReference
Coolant capacity41.6 LReference
Transmission
4-speed power shiftReference
Typepower shiftReference
Gears4 forward and reverseReference
Oil capacity132.5 LReference
Dimensions
Weight11113 kgReference
18-inch tracksReference
Length386 cmReference
15D-2 dozer length502 cmReference
15G-2 dozer length518 cmReference
Width233 cmReference
Height (steering wheel)218 cmReference
Height (ROPS)294 cmReference
International Harvester TD-15C attachments
bladeReference
TD-15C Serial Numbers
1972501Reference
19731130Reference
19741849Reference
19752750Reference
19763322Reference
19773621Reference
19783960Reference
19794516Reference
19804901Reference
19815196Reference
19825701Reference
FAQ: How to read a serial number table.Reference
International Harvester TD-15C Tracks
Width45 cmReference
Length on ground244 cmReference
Area on ground2.2 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
