Tractor · 1947Unverified
International Harvester TD-24
International Harvester TD-24 — Agricultural Crawler tractor · 111 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
111 hp
Max power
106.0 kW
Weight
17395 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Agricultural Crawler tractorReference
Built in Melrose Park, Illinois, USAReference
Total built7,500Reference
DrivecrawlerReference
SteeringhydraulicReference
Open operator station.Reference
Engine
International Harvester 17.9L 6-cyl dieselReference
Fuel tank321.7 LReference
Aux. fuel8.1 LReference
Drawbar (claimed)82.8 kWReference
Drawbar (tested)125.3 kWReference
International HarvesterReference
dieselReference
6-cylinderReference
liquid-cooled vertical I-headReference
Displacement17.9 LReference
Bore/Stroke146 x 178 mmReference
Compression15.22:1Reference
Rated RPM1375Reference
Startergasoline-ignitionReference
Starter volts24Reference
Oil capacity28.4 LReference
Coolant capacity140.1 LReference
Max power106.0 kWReference
Max power114.9 kWReference
Max power125.3 kWReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and reverseReference
Clutchdry discReference
Dimensions
Weight17395 kgReference
TracksReference
Length463 cmReference
Width259 cmReference
Height242 cmReference
Shipping weight17395 kgReference
TD-24 Serial Number Location
Left side of dashboard.Reference
TD-24 Serial Numbers
1947506 (TDE)Reference
1948515 (TDE)Reference
19491501 (TDE)Reference
19501967 (TDE)Reference
19512915 (TDE)Reference
19524120 (TDE)Reference
195350075 (TDE)Reference
19546049 (TDE)Reference
19556556 (TDE)Reference
19558001 (241)Reference
19568793 (241)Reference
19579655 (241)Reference
195810330 (241)Reference
19591598 (241)Reference
1955601 (241 TC)Reference
1956826 (241 TC)Reference
19571249 (241 TC)Reference
19581420 (241 TC)Reference
19591598 (241 TC)Reference
FAQ: How to read a serial number table.Reference
Test results
NTTL 447: diesel 8-speed crawlerReference
NTTL 529: diesel 8-speed crawlerReference
NTTL 630: diesel 8-speed crawlerReference
Diesel 8-speed crawlerJune 29 - July 18, 1950Link: Nebraska Tractor Test 447 fileReference
Drawbar performanceReference
Gear 3 used for power test.Reference
Max pull15292 kgReference
Gear 1 used for pull test.Reference
Diesel 8-speed crawlerOctober 22 - 29, 1954Link: Nebraska Tractor Test 529 fileReference
Max pull16855 kgReference
Diesel 8-speed crawlerSeptember 3 - 14, 1957Link: Nebraska Tractor Test 630 fileReference
Max pull18656 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
