Tractor · 1912Unverified
International Harvester Titan 18-35
International Harvester Titan 18-35 — Titan Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
15700 to 16850 pounds
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Standard-tread tractorReference
Built in Milwaukee, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station with canopy.Reference
Engine
International Harvester 16.5L 2-cyl keroseneReference
Fuel tank165.6 LReference
Aux. fuel75.7 LReference
Drawbar (claimed)13.4 kWReference
Belt (claimed)26.1 kWReference
International HarvesterReference
keroseneReference
2-cylinderReference
liquid-cooledReference
Displacement16.5 LReference
Bore/Stroke203 x 254 mmReference
Cooling systemevaporativeReference
Rated RPM425Reference
Starter typecompressed airReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight15700 to 16850 poundsReference
Front tire38x9Reference
Rear tire63x22Reference
Ag front38x9 (steel)Reference
Ag rear63x22 (steel)Reference
Length468 cmReference
Width243 cmReference
Height312 cmReference
Shipping weight7121 kgReference
Operating weight7643 kgReference
Titan 18-35 Serial Numbers
1912TC101 (hit-miss)Reference
1913TC103 (hit-miss)Reference
FinalTC103 (hit-miss)Reference
1913TB101 (throttle)Reference
1914TB220 (throttle)Reference
FinalTB238Reference
1914TF101Reference
1915TF171Reference
FinalTF218Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter60 cmReference
Width31 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
