Tractor · 1908Unverified

International Harvester Type B 20HP

Name: International Harvester Type B 20HP
Brand: International Harvester

International Harvester Type B 20HP — Standard-tread tractor · 20 hp. Reference specifications; pending source verification.

The International Harvester Type B 20HP is a compact tractor rated at 20 hp, manufactured from 1908 to 1913. It features a 1-cylinder petrol liquid-cooled engine, coupled with a 1-speed gearbox and two-wheel drive configuration. The tractor has a listed weight of 5715 kg and is designed for handling tasks on land areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Weight

5715 kg

Catalogue coverage

Variants represented

Richest spec table

29 rows

Recorded power

20 hp

Recorded weight

5715 kg

Transmissions

1-speed gear

Production years

1908-1913

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorInternational HarvesterReference

ManufacturerOhio Manufacturing CompanyReference

Standard-tread tractorReference

Built in Upper Sandusky, Ohio, USAReference

Two-wheel driveReference

Manual steeringReference

Open operator station with canopy.Reference

Engine

International Harvester 14.8L 1-cyl gasolineReference

Fuel tank94.6 LReference

Belt (claimed)14.9 kWReference

Plows4Reference

International Harvester FamousReference

gasolineReference

1-cylinderReference

liquid-cooledReference

Displacement14.8 LReference

Bore/Stroke222 x 381 mmReference

Cooling systemevaporativeReference

Operating RPM240-290Reference

Coolant capacity219.6 LReference

Transmission

1-speed gearReference

2-speed gearReference

TypegearReference

Gears1 forward and reverseReference

Gears2 forward and 1 reverseReference

Dimensions

Weight5715 kgReference

Rear tire64x18Reference

Ag rear64x18 (steel)Reference

Height259 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
