Tractor · 1918Unverified

Interstate Tractor Plow Man 15-30

Interstate Tractor Plow Man 15-30 · 15 hp. Reference specifications; pending source verification.

The Interstate Tractor Plow Man 15-30 is a compact tractor model with a rated output of 15 hp. It was manufactured from 1918 to 1920 and features a 4-cylinder liquid-cooled engine that powers two-wheel drive through a 2-speed gearbox. The listed weight of the Plow Man 15-30 is 2177 kg, and it is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
15 hp
Weight
2177 kg

Catalogue coverage

Variants represented
2
Richest spec table
32 rows
Recorded power
15 hp
Recorded weight
2177 kg
Transmissions
2-speed sliding gear
Production years
1918-1920
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerInterstate TractorReference
Built in Waterloo, Iowa, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference

Engine

Buda 6.3L 4-cyl keroseneReference
Fuel tank64.3 LReference
Aux. fuel11.4 LReference
Drawbar (claimed)11.2 kWReference
Belt (claimed)22.4 kWReference
Plows3 (14-inch)Reference
BudaReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement6.3 LReference
Bore/Stroke114 x 152 mmReference
Fuel systemBennett carburetorReference
Starter typehand-crankReference

Transmission

2-speed sliding gearReference
Typesliding gearReference
Gears2 forwardReference

Dimensions

Weight2177 kgReference
Rear tire60x10Reference
Ag rear60x10 steelReference
Length396 cmReference
Width167 cmReference
Height175 cmReference

Capacities

Diameter35 cmReference
Width20 cmReference
RPM590Reference
Speed655.32 meters/minReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
