Tractor · 2010Unverified
Iseki AT240
Iseki AT240 — AT Series · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
2866 to 3175 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank35.0 LReference
Engine17.7 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power17.7 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM569@2500Reference
Engine RPM765@2500Reference
Engine RPM942@2500Reference
Engine RPM1227@2500Reference
Engine RPM-765@2500Reference
Dimensions
Wheelbase163 cmReference
Weight2866 to 3175 poundsReference
Front tire7-14Reference
Rear tire9.5-24Reference
Standard tires (ag)Front: 7-14. Rear: 9.5-24Reference
Length302 cmReference
Width128 cmReference
Height (ROPS)196 cmReference
Height (cab)197 cmReference
ROPS Weight1300 kgReference
Cab Weight1440 kgReference
Ground clearance32 cmReference
Front tread96 cmReference
Rear tread101/117 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
