Tractor · 2010Unverified
Iseki AT280 Semi-Crawler
Iseki AT280 Semi-Crawler — AT Series · 28 hp. Reference specifications; pending source verification.
The Iseki AT280 Semi-Crawler is a tractor with a power rating of approximately 28 horsepower, positioning it at the lower end of its class. It was manufactured between 2010 and 2012. This model is equipped with a 3-cylinder diesel liquid-cooled engine and features a tracked undercarriage paired with a 24-speed gearbox, with an operating weight of 1875 kg. Its capabilities extend to working on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1875 kg
Catalogue coverage
Variants represented
2
Richest spec table
45 rows
Recorded power
28 hp
Recorded weight
1875 kg
Transmissions
24-speed
Production years
2010-2012
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
AT280wheeledReference
AT280Chalf-trackReference
Engine
Iseki 1.6L 3-cyl dieselReference
Fuel tank35.0 LReference
Engine20.6 kWReference
Iseki E3CGReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke87 x 92 mmReference
Power20.6 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM569@2500Reference
Engine RPM765@2500Reference
Engine RPM942@2500Reference
Engine RPM1227@2500Reference
Engine RPM-765@2500Reference
Dimensions
Wheelbase167 cmReference
Weight1875 kgReference
Front tire8-16Reference
Rear tiretracksReference
Ag front8-16Reference
Ag reartracksReference
Length308 cmReference
Width156 cmReference
Height (cab)199 cmReference
Ground clearance37 cmReference
Front tread118 cmReference
Rear tread117 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
