Tractor · 2010Unverified
Iseki AT280 Semi-Crawler
Iseki AT280 Semi-Crawler — AT Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1875 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
AT280wheeledReference
AT280Chalf-trackReference
Engine
Iseki 1.6L 3-cyl dieselReference
Fuel tank35.0 LReference
Engine20.6 kWReference
Iseki E3CGReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke87 x 92 mmReference
Power20.6 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM569@2500Reference
Engine RPM765@2500Reference
Engine RPM942@2500Reference
Engine RPM1227@2500Reference
Engine RPM-765@2500Reference
Dimensions
Wheelbase167 cmReference
Weight1875 kgReference
Front tire8-16Reference
Rear tiretracksReference
Ag front8-16Reference
Ag reartracksReference
Length308 cmReference
Width156 cmReference
Height (cab)199 cmReference
Ground clearance37 cmReference
Front tread118 cmReference
Rear tread117 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
