Tractor · 2004Unverified
Iseki AT30
Iseki AT30 — AT Series · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
3020 to 3274 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank35.0 LReference
Engine22.1 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power22.1 kWReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
24-speedReference
Gears16 forward and reverseReference
Clutchdry discReference
Gears24 forward and reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM588@2800Reference
Engine RPM790@2800Reference
Engine RPM974@2800Reference
Engine RPM1268@2800Reference
Engine RPM-790@2800Reference
Dimensions
Wheelbase169 cmReference
Weight3020 to 3274 poundsReference
Front tire8-16Reference
Rear tire12.4-26Reference
Standard tires (ag)Front: 8-16. Rear: 12.4-26Reference
Length309 cmReference
Width141 cmReference
Height (ROPS)199 cmReference
Height (cab)199 cmReference
ROPS Weight1369 kgReference
Cab Weight1485 kgReference
Ground clearance38 cmReference
Front tread115 cmReference
Rear tread109 to 141 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
