Tractor · 2013Unverified
Iseki AT5330
Iseki AT5330 — AT Series · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
1230 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Power steeringReference
Open operator station.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine24.2 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Power24.2 kWReference
Air cleanerdual element dryReference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
9-speed gearReference
TypegearReference
Gears9 forward and 3 reverseReference
Clutchdry discReference
PTO & Hydraulics
Pump flow33.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift1270 kgReference
Rear PTO Type690/820Reference
Dimensions
Wheelbase177 cmReference
Weight1230 kgReference
Front tire7-16Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference
Length311 cmReference
Width145 cmReference
Height151 cmReference
Ground clearance35 cmReference
Front tread109 cmReference
Rear tread109 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
