Tractor · 2013Unverified
Iseki AT5470
Iseki AT5470 — AT Series · 48 hp. Reference specifications; pending source verification.
The Iseki AT5470 is a tractor rated at 48 hp — making it one of the more compact options in its class. The AT5470 was manufactured in 2013. It is powered by a 4-cylinder diesel liquid-cooled engine, driving through a 8-speed gearbox. Listed weight is 1525 kg, and it is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
48 hp
Weight
1525 kg
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
48 hp
Recorded weight
1525 kg
Transmissions
8-speed shuttle
Production years
2013-2013
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Power steeringReference
Open operator station.Reference
Engine
Iseki 2.2L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine35.6 kWReference
Iseki E4CGReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Power35.6 kWReference
Air cleanerdual element dryReference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
8-speed shuttleReference
TypeshuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Pump flow34.4 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift1579 kgReference
Rear PTO Type694/822Reference
Dimensions
Wheelbase189 cmReference
Weight1525 kgReference
Front tire8-18Reference
Rear tire13.6-26Reference
Standard tires (ag)Front: 8-18. Rear: 13.6-26Reference
Length343 cmReference
Width155 cmReference
Height159 cmReference
Ground clearance36 cmReference
Front tread124 cmReference
Rear tread123 to 155 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
