Tractor · 2013Unverified
Iseki AT5520
Iseki AT5520 — AT Series · 53 hp. Reference specifications; pending source verification.
The Iseki AT5520 is a tractor with a rated output of 53 hp, classified as one of the more compact options in its class. It was manufactured in 2013. The tractor features a 4-cylinder diesel liquid-cooled engine, which is connected to an 8-speed gearbox. Its listed weight is 1599 kg, with an operational capacity of approximately 200 ac.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
53 hp
Weight
1599 kg
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
53 hp
Recorded weight
1599 kg
Transmissions
8-speed shuttle
Production years
2013-2013
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Power steeringReference
Open operator station.Reference
Engine
Iseki 3.0L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine39.4 kWReference
Iseki E4DEReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Power39.4 kWReference
Air cleanerdual element dryReference
Rated RPM2500Reference
Starter typeelectricReference
Transmission
8-speed shuttleReference
TypeshuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Pump flow36.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift1579 kgReference
Rear PTO Type667/790Reference
Dimensions
Wheelbase193 cmReference
Weight1599 kgReference
Front tire9.5-16Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 9.5-16. Rear: 13.6-28Reference
Length343 cmReference
Width153 cmReference
Height162 cmReference
Ground clearance36 cmReference
Front tread135 cmReference
Rear tread121 to 153 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
