Tractor · 2023Unverified
Iseki RTS255
Iseki RTS255 — RTS5 Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2227 to 2579 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine18.4 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power18.4 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
30-speed partial power shiftReference
TypegearReference
Gears12 forward and reverseReference
Clutchdry discReference
Four gears in three ranges with mechanical shuttle.Reference
Typepartial power shiftReference
Gears30 forward and reverseReference
Ten power shift gears in three ranges with power shuttle.Reference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM523@2500Reference
Engine RPM819@2500@1266@2500Reference
Dimensions
Wheelbase150 cmReference
Weight2227 to 2579 poundsReference
Front tire7-16Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference
Optional tires (ag)Front: 6.00-12. Rear: 8.3-22Reference
Optional tires (ag)Front: 7-14. Rear: 9.5-24Reference
Optional tires (ag)Front: 24x8.5-12. Rear: 315/75D-15Reference
Optional tires (ag)Front: 7-14. Rear: 8.3-24Reference
Length280 cmReference
Width133 cmReference
Height (ROPS)198 cmReference
ROPS Weight1010 kgReference
Cab Weight1169 kgReference
Ground clearance36 cmReference
Front tread103 cmReference
Rear tread104 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
