Tractor · 1985Unverified
Iseki SX55
Iseki SX55 — SX Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
1384 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS with canopy.Reference
Engine
Isuzu 2.8L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine37.3 kWReference
Isuzu 4JB1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Bore/Stroke93 x 102 mmReference
Power37.3 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Pre-heatingglow plugsReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed syncromeshReference
24-speed creeperReference
TypesyncromeshReference
Gears12 forward and 4 reverseReference
Clutch330mm dry discReference
TypecreeperReference
Gears24 forward and 8 reverseReference
PTO & Hydraulics
Pump flow35.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2399 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1727Reference
Engine RPM1000@2000Reference
Dimensions
Wheelbase215 cmReference
Weight1384 kgReference
Front tire8.3-20Reference
Rear tire14.9-28Reference
Standard tires (ag)Front: 8.3-20. Rear: 14.9-28Reference
Length356 cmReference
Height (exhaust)188 cmReference
Ground clearance31 cmReference
Front tread135 to 152 cmReference
Rear tread128 to 177 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
