Lawn Tractor · 2007Unverified
Iseki SXG22
Iseki SXG22 — Garden tractor · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
509 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Garden tractorReference
Two-wheel driveReference
SteeringpowerReference
Expanding shoe brakesReference
Open operator station.Reference
Engine
22HP Iseki 1122cc 3-cyl dieselReference
Fuel tank18.5 LReference
Iseki E3112Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement68.5 ciReference
Bore/Stroke78 x 78 mmReference
Power16.4 kWReference
Fuel systemdirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTO Type1750Reference
Dimensions
Wheelbase145 cmReference
Weight509 kgReference
Front tire210/60D-8Reference
Rear tire250/60D-14Reference
Lawn/turf front210/60D-8Reference
Lawn/turf rear250/60D-14Reference
Length211 cmReference
Width113 cmReference
Height126 cmReference
Ground clearance14 cmReference
Iseki SXG22 attachments
48" mid-mount mower deckReference
54" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
48" mid-mount mower deckReference
54" mid-mount mower deckReference
The Iseki SXG2 was available with the model 550 hydraulic-dump collection system with a 550 liter capacity.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
