Tractor · 1990Unverified
Iseki T7020
Iseki T7020 — Landmax T20 Series · 69 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
69 hp
Weight
3279 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS. Cab optional.Reference
Engine
Isuzu 3.9L 4-cyl dieselReference
Engine51.2 kWReference
Isuzu 4BD1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke102 x 118 mmReference
Power51.2 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed syncromeshReference
24-speed creeperReference
TypesyncromeshReference
Gears12 forward and 4 reverseReference
Four gears (1-4) in three ranges (L/M/H) plus reverse (R) range.Reference
TypecreeperReference
Gears24 forward and 8 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Weight3279 kgReference
Front tire9.5-22Reference
Rear tire12.4-36Reference
Ag front9.5-22Reference
Ag rear12.4-36Reference
Length385 cmReference
Width179 cmReference
Height258 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
