Tractor · 1990Unverified
Iseki T8020
Iseki T8020 — Landmax T20 Series · 78 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
78 hp
Weight
3709 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS. Cab optional.Reference
Engine
Isuzu 5.4L 6-cyl dieselReference
Engine58.5 kWReference
Isuzu 6BB1Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.4 LReference
Bore/Stroke102 x 110 mmReference
Power58.5 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed syncromeshReference
24-speed creeperReference
TypesyncromeshReference
Gears12 forward and 4 reverseReference
TypecreeperReference
Gears24 forward and 8 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Weight3709 kgReference
Front tire11.2-24Reference
Rear tire16.9-34Reference
Ag front11.2-24Reference
Ag rear16.9-34Reference
Length416 cmReference
Width198 cmReference
Height264 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
