Tractor · 1989Unverified
Iseki TA207
Iseki TA207 — Landleader TA7 Series · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
2189 to 2862 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station. Cab optional.Reference
Variants
TA207F4WDReference
Engine
Iseki 1.4L 3-cyl dieselReference
Fuel tank21.2 LReference
Engine14.7 kWReference
Iseki E3AG1Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke84 x 86 mmReference
Power14.7 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity4.8 LReference
Transmission
16-speedReference
Gears16 forward and reverseReference
Four gears (1-4) in four ranges with shuttle shift.Reference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Engine RPM565@2500Reference
Engine RPM733@2500Reference
Engine RPM1060@2500Reference
Engine RPM1244@2500Reference
Dimensions
Wheelbase153 cmReference
Weight2189 to 2862 poundsReference
Front tire4.00-15Reference
2WD Rear tire8.3-24Reference
2WD Standard tires (ag)Front: 4.00-15. Rear: 8.3-24Reference
4WD Standard tires (ag)Front: 6-14. Rear: 8.3-24Reference
Length290 cmReference
Width124 cmReference
Height (steering wheel)139 cmReference
Height (cab)194 cmReference
Ground clearance26 cmReference
2WD Front tread90/101 cmReference
4WD Front tread94 cmReference
Rear tread93/108 cmReference
2WD Open992 kgReference
4WD Open1078 kgReference
2WD Cab1212 kgReference
4WD Cab1298 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
