Tractor · 1989Unverified
Iseki TA227
Iseki TA227 — Landleader TA7 Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
2194 to 2866 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station. Cab optional.Reference
Variants
TA227F4WDReference
Engine
Iseki 1.4L 3-cyl dieselReference
Fuel tank21.2 LReference
Engine16.2 kWReference
Iseki E3AG1Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke84 x 86 mmReference
Power16.2 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity4.8 LReference
Transmission
16-speedReference
Gears16 forward and reverseReference
Four gears (1-4) in four ranges with shuttle shift.Reference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Engine RPM565@2500Reference
Engine RPM733@2500Reference
Engine RPM1060@2500Reference
Engine RPM1244@2500Reference
Dimensions
Wheelbase156 cmReference
Weight2194 to 2866 poundsReference
Front tire4.00-15Reference
2WD Rear tire9.5-22Reference
2WD Standard tires (ag)Front: 4.00-15. Rear: 9.5-22Reference
4WD Standard tires (ag)Front: 6-14. Rear: 9.5-22Reference
Length290 cmReference
Width124 cmReference
Height (steering wheel)139 cmReference
Height (cab)189 cmReference
Ground clearance26 cmReference
2WD Front tread90/101 cmReference
4WD Front tread107 cmReference
Rear tread93/108 cmReference
2WD Open995 kgReference
4WD Open1080 kgReference
2WD Cab1215 kgReference
4WD Cab1300 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
