Tractor · 1989Unverified

Iseki TA227

Name: Iseki TA227
Brand: Iseki

Iseki TA227 — Landleader TA7 Series · 22 hp. Reference specifications; pending source verification.

The Iseki TA227 is a compact tractor with a rating of 22 hp. It was produced from 1989 to 1992. The tractor features a 3-cylinder diesel liquid-cooled engine, which transmits power through a four-wheel drive system to a 16-speed gearbox. Its listed weight range is 2194 to 2866 pounds, suitable for tasks involving up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Weight

2194 to 2866 pounds

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

22 hp

Transmissions

16-speed

Production years

1989-1992

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerIsekiReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Open operator station. Cab optional.Reference

Variants

TA227F4WDReference

Engine

Iseki 1.4L 3-cyl dieselReference

Fuel tank21.2 LReference

Engine16.2 kWReference

Iseki E3AG1Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.4 LReference

Bore/Stroke84 x 86 mmReference

Power16.2 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Oil capacity4.8 LReference

Transmission

16-speedReference

Gears16 forward and reverseReference

Four gears (1-4) in four ranges with shuttle shift.Reference

PTO & Hydraulics

Rear PTO Type540 (1.375)Reference

Engine RPM565@2500Reference

Engine RPM733@2500Reference

Engine RPM1060@2500Reference

Engine RPM1244@2500Reference

Dimensions

Wheelbase156 cmReference

Weight2194 to 2866 poundsReference

Front tire4.00-15Reference

2WD Rear tire9.5-22Reference

2WD Standard tires (ag)Front: 4.00-15. Rear: 9.5-22Reference

4WD Standard tires (ag)Front: 6-14. Rear: 9.5-22Reference

Length290 cmReference

Width124 cmReference

Height (steering wheel)139 cmReference

Height (cab)189 cmReference

Ground clearance26 cmReference

2WD Front tread90/101 cmReference

4WD Front tread107 cmReference

Rear tread93/108 cmReference

2WD Open995 kgReference

4WD Open1080 kgReference

2WD Cab1215 kgReference

4WD Cab1300 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
